Features
- Stock No.169304
- Model: HVS-100
- Size:4"/100mm
- Width of the jaw: 3.94" / 100mm
- Max. Opening: 4.06" / 103mm
- Clamping Force: 10KN
- Packing Size(in): 12"x6"x7"
- N.W/G.W(lb): 11.5/12.5
